74.5" Konka 75U55A - Specifications

WidthHeightDepthWeightWrite a review
SpecificationsDisplay
Display: 74.5 in, VA, Direct LED, 3840 x 2160 pixels
Viewing angles (H/V): 178 ° / 178 °
Refresh rate: 50 Hz / 60 Hz
TV tuner: Analog (NTSC/PAL/SECAM), ATSC, Clear QAM
Cores: 4
Dimensions: 1673 x 959 x 74 mm
Weight: 22.7 kg

Add to compare Suggest an edit

Brand, series, model

Information about the brand, series, model and model aliases.

Brand

Name of the company-manufacturer.

Konka
Series

Name of the series, which the model belongs to.

U5
Model

Designation of the model.

75U55A
Model year

The year in which this model was announced.

2020

Display

Information about the main characteristics of the display - panel, backlight, resolution, refresh rate, etc.

Size class

Size class of the display as declared by the manufacturer. Often this is the rounded value of the actual size of the diagonal in inches.

74.5 in (inches)
Diagonal

Approximate diagonal size of the display. If the manufacturer does not provide such information, the diagonal is calculated from the width and height of the screen.

1893 mm (millimeters)
189.3 cm (centimeters)
74.5276 in (inches)
6.2106 ft (feet)
Width

Approximate width of the display. If the manufacturer does not provide such information, the width is calculated from the diagonal and the aspect ratio.

1650.24 mm (millimeters)
165.024 cm (centimeters)
64.9701 in (inches)
5.4142 ft (feet)
Height

Approximate height of the display. If the manufacturer does not provide such information, the height is calculated from the diagonal and the aspect ratio.

928.26 mm (millimeters)
92.826 cm (centimeters)
36.5457 in (inches)
3.0455 ft (feet)
Panel type

There are various panel technologies. Each has its own specific features - viewing angles, color reproduction, response time, brightness/contrast, production cost, etc. The image quality depends directly on the type of the display panel used.

VA
Panel bit depth

The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.

10 bits (8 bits + FRC)
FRC

Frame Rate Control (FRC) is a method, which allows the pixels to show more color tones. With quick cyclic switching between different color tones, an illusion for a new intermediate color tone is created. For example, by using FRC, a 6-bit display panel is able to show 16.7 millioin colors, which are typical for 8-bit display panels, and not the standard 262200 colors, instead. There are different FRC algorithms.

Yes
Colors

The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.

1073741824 colors
30 bits
Aspect ratio

The ratio between the horizontal and the vertical side of the display. Some of the standard and widely used aspect ratios are 4:3, 5:4, 16:9 and 16:10.

1.778:1
16:9
Resolution

Information about the number of pixels on the horizontal and vertical side of the screen. A higher resolution allows the display of a more detailed and of higher quality image.

3840 x 2160 pixels
Ultra HD (UHD) / 4K / 2160p
Pixel pitch

The pixel pitch shows the distance from the centers of two neighboring pixels. In displays, which have a native resolution (the TFT ones, for example), the pixel pitch depends on the resolution and the size of the screen.

0.43 mm (millimeters)
0.043 cm (centimeters)
0.0169 in (inches)
0.0014 ft (feet)
Pixel density

Information of the number of pixels in a unit of length. With the decrease of the display size and the increase of its resolution, the pixel density increases.

59 ppi (pixels per inch)
23 ppcm (pixels per centimeter)
Display area

The percentage of the approximate area, taken by the active part of the screen, to the total front area.

95.48 % (percent)
Backlight

The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.

Direct LED
HDR

HDR expands the contrast ratio (peak luminance and minimal black levels) and color palette to achieve more details across the whole image - from the darkest parts to the brightest ones, which results in more realistic and life-like image.

HDR10
Horizontal viewing angle

Information about the maximum horizontal viewing angle, within which the image on the screen is of acceptable quality.

178 ° (degrees)
Vertical viewing angle

Information about the maximum vertical viewing angle, within which the image on the screen is of acceptable quality.

178 ° (degrees)

3D

3D displays use various technologies to achieve a 3D effect. Each of these technologies has its own advantages and drawbacks.

3D

Information on whether 3D is supported or not.

No

Frequencies

Information about the horizontal and vertical refresh rates/frequencies.

Vertical frequency (digital)

The vertical frequency/refresh rate shows how many times in a second the image on the screen is refreshed.

50 Hz / 60 Hz (hertz)

Frame interpolation

Many smart TV sets use a technology for interpolating (inserting) of intermediate frames between existing ones in order to achieve more fluent visualization, especially for dynamic scenes.

Interpolation technology

Frame interpolation technologies differ according to the manufacturer and each has its own specific name.

AccuMotion

Power supply and consumption

Information about the power supply and consumption, energy efficiency class, etc.

110V

Permissible voltage tolerance in a 110-volt electric system.

100 V - 120 V (volts)
Alternating current frequency

Requirement regarding the alternating current frequency in the electric system.

50 Hz - 60 Hz (hertz)
Power consumption (sleep)

Power consumption in sleep/stand by/suspend mode.

0.5 W (watts)
Power consumption (annual)

Estimated power consumption per year in kWh.

430 kWh (kilowatt-hours)

Dimensions, weight and color

Information about the dimensions and the weight of the specific model with and without stand as well as the colors, in which it is offered to the market.

Width

Width without stand in different measurement units.

1673 mm (millimeters)
167.3 cm (centimeters)
65.8661 in (inches)
5.4888 ft (feet)
Height

Height without stand in different measurement units.

959 mm (millimeters)
95.9 cm (centimeters)
37.7559 in (inches)
3.1463 ft (feet)
Depth

Depth without stand in different measurement units.

74 mm (millimeters)
7.4 cm (centimeters)
2.9134 in (inches)
0.2428 ft (feet)
Weight

Weight without stand in different measurement units.

22.7 kg (kilograms)
50.04 lbs (pounds)
Width with stand

Width with stand in different measurement units.

1673 mm (millimeters)
167.3 cm (centimeters)
65.8661 in (inches)
5.4888 ft (feet)
Height with stand

Height with stand in different measurement units.

1030 mm (millimeters)
103 cm (centimeters)
40.5512 in (inches)
3.3793 ft (feet)
Depth with stand

Depth with stand in different measurement units.

317 mm (millimeters)
31.7 cm (centimeters)
12.4803 in (inches)
1.04 ft (feet)
Weight with stand

Weight with stand in different measurement units.

23 kg (kilograms)
50.71 lbs (pounds)
Box width

Width of the package in different measurement units.

1825 mm (millimeters)
182.5 cm (centimeters)
71.8504 in (inches)
5.9875 ft (feet)
Box height

Height of the package in different measurement units.

1105 mm (millimeters)
110.5 cm (centimeters)
43.5039 in (inches)
3.6253 ft (feet)
Box depth

Depth of the package in different measurement units.

245 mm (millimeters)
24.5 cm (centimeters)
9.6457 in (inches)
0.8038 ft (feet)
Box weight

Weight of the product with all accessories and packaging in different measurement units.

33.8 kg (kilograms)
74.52 lbs (pounds)
Colors

Information about the colors, in which the specific model is offered to the market.

Black

Ergonomics

Information about the ergonomic functions - height adjustment, swivel angles, tilt angles, etc.

VESA mount

Information about whether there is a possibility for wall mounting according to the VESA Mounting Interface Standard (MIS).

Yes
VESA interface

There are many various interfaces under the VESA standard, which differ in the size of the brackets, the distances between the screw holes and their number.

400 x 300 mm
Removable stand

Information about whether the stand can be dismounted. Usually, this is required for wall mounting.

Yes
Height adjustment

Information about whether the stand allows height adjustment.

No
Landscape/portrait pivot

Some displays have the ability to operate in landscape and portrait mode alike.

No
Left/right swivel

Information whether the display can be swiveled around the stand axis.

No
Forward/backward tilt

Most displays have the ability to be tilted forward and backward as to provide a more comfortable viewing position for the user.

No

TV tuner

The TV tuner is a device, which allows the receiving and visualization of a certain type of television signal. There are tuners for digital, analog, cable and satellite television.

TV tuner

Information about the TV tuners, which the current model is equipped with.

Analog (NTSC/PAL/SECAM)
ATSC
Clear QAM

System on Chip (SoC)

Information about the central processor, graphic processor and the memory of the model.

CPU cores

The software instructions are performed by the CPU cores. The higher number of cores allows for the parallel (simultaneous) processing of more instructions and achieving higher performance. There are various processors equipped with 1, 2, 4, 6, 8, and more cores.

4

OS, apps and software features

Information about the operating system, applications, various software features if available.

Operating system (OS)

The operating systems of the smart TV sets feature user interface technologies for navigation and other ways of interaction with the smart TV - installing applications, internet browsing, video calls, sharing content with other users, playing videos and music, etc.

Android 9.0 Pie

Audio

Information about the audio system - number and power of the built-in speakers, supported audio technologies.

Speakers

The speaker is a device, which converts electrical audio signals into acoustic vibrations resulting in corresponding sounds.

2 x 10 W (watts)
Dolby Digital Plus

Camera

Many contemporary desktop monitors and smart TV sets have built-in cameras.

Camera

Information whether the current model has a built-in camera or not.

No

Network

Supported network technologies and standards for exchanging data with other devices.

Network

Information about the network technologies and standards supported by the model, which allow for it to connect to and communicate with other devices.

LAN
Wi-Fi
802.11a (IEEE 802.11a-1999)
802.11b (IEEE 802.11b-1999)
802.11g (IEEE 802.11g-2003)
802.11n (IEEE 802.11n-2009)
802.11n 5GHz
802.11ac (IEEE 802.11ac)
Wi-Fi Direct
Bluetooth 5.0

Connectivity

Available connectivity ports, slots and interfaces.

Connectivity

Information about the available connectivity ports, slots and interfaces such as USB, infrared port, SD card slot, audio/video and network interfaces, etc.

3 x USB 2.0
1 x Ethernet RJ45
4 x HDMI 2.0 (ARC; CEC)
1 x Cable/Antenna In (F-type female)
1 x AV Composite In 3.5 mm jack
1 x Optical Audio Out
1 x 3.5 mm Audio Out
High-bandwidth Digital Content Protection (HDCP) 2.2

Features

Some additional functional features of the model.

Features

Information about additional software features, technologies, functions and services of the model.

AccuMotion Enhanced Motion Rate
Chromecast built-in
ColorWave Wide Color Gamut
CrystalView Multi-Function Clarity Enhancer
DeepBlack Dynamic Contrast Enhancer
Game Mode
Google Assistant
HiBright Pro LED Backlight
Konka XC3 Quad Core+ Ultra HD Engine
PurePalette Wide Color Enhancer
Voice Command
ZeroBezel Design

Image file formats

Smart TV sets allow the display of different image file formats.

Image file formats

Information about some of the main image file formats supported by the current model.

JPEG
GIF
PNG

Audio file formats

Smart TV sets allow playing different audio file formats.

Audio file formats/codecs

Information about some of the main audio file formats/codecs supported by the current model.

3GPP (3rd Generation Partnership Project, .3gp)
AAC (Advanced Audio Coding)
AAC+ / aacPlus / HE-AAC v1
FLAC (Free Lossless Audio Codec, .flac)
M4A (MPEG-4 Audio, .m4a)
MP3 (MPEG-2 Audio Layer II, .mp3)
WMA (Windows Media Audio, .wma)
WAV (Waveform Audio File Format, .wav, .wave)

Video file formats

Smart TV sets allow playing various video file formats.

Video file formats/codecs

Information about some of the main video file formats/codecs supported by the current model.

3GPP (3rd Generation Partnership Project, .3gp)
AVI (Audio Video Interleaved, .avi)
DivX (.avi, .divx, .mkv)
H.263
H.264 / MPEG-4 Part 10 / AVC video
H.265 / MPEG-H Part 2 / HEVC
MKV (Matroska Multimedia Container, .mkv .mk3d .mka .mks)
MP4 (MPEG-4 Part 14, .mp4, .m4a, .m4p, .m4b, .m4r, .m4v)
MPEG-4
WMV (Windows Media Video, .wmv)

Accessories

Often the packaging of desktop monitors and smart TV sets includes accessories for them.

Accessories

Information about some of the main accessories included in the standard packaging of the current model.

Voice Remote Control

Other models from the U5 series of Konka

List of other models from the same Konka series, to which the Konka 75U55A belongs.

View
42.5" Konka 43U55A, VA, Direct LED, 3840 x 2160 pixels, 50 Hz / 60 Hz, 959.8 x 556 x 62 mm, 7.1 kg
View
49.5" Konka 50U55A, VA, Direct LED, 3840 x 2160 pixels, 50 Hz / 60 Hz, 1115.2 x 642.3 x 60 mm, 10.6 kg
View
54.6" Konka 55U55A, VA, Direct LED, 3840 x 2160 pixels, 50 Hz / 60 Hz, 1229 x 710 x 61 mm, 12.7 kg
View
64.5" Konka 65U55A, VA, Direct LED, 3840 x 2160 pixels, 50 Hz / 60 Hz, 1448 x 828.8 x 61 mm, 17 kg

Latest comparisons that include Konka 75U55A

The latest comparisons, made by the website visitors, that include Konka 75U55A.

Konka 75U55A
Konka 75Q75A
View
Konka 75U55A
Konka 75Q75A
Konka 65" 812 Series OLED
View
Konka 75U55A
TCL 85C645
TCL 75C645
View
Konka 65" 812 Series OLED
Acer QG241Y Ebii
Konka 75U55A
Philips 55PML9008/12
View
Konka 75U55A
LG OLED83M3PUA
View
Konka 55" 812 Series OLED
Konka 75U55A
View
Konka 50U55A
Konka 55U55A
Konka 65U55A
Konka 75U55A
View
Konka 75U55A
Xiaomi Mi TV 4X 65 L65M5-5SIN
View

Last viewed models

A list of the last viewed desktop monitors and TVs.

Konka 75U55A

74.5" Konka 75U55A

Display: 74.5 in, VA, Direct LED, 3840 x 2160 pixels
Viewing angles (H/V): 178 ° / 178 °
Refresh rate: 50 Hz / 60 Hz
TV tuner: Analog (NTSC/PAL/SECAM), ATSC, Clear QAM
Cores: 4
Dimensions: 1673 x 959 x 74 mm
Weight: 22.7 kg
