Name of the company-manufacturer.
Name of the series, which the model belongs to.
Designation of the model.
The year in which this model was announced.
Size class of the display as declared by the manufacturer. Often this is the rounded value of the actual size of the diagonal in inches.
|84.6 in (inches)|
Approximate diagonal size of the display. If the manufacturer does not provide such information, the diagonal is calculated from the width and height of the screen.
|2140 mm (millimeters)|
214 cm (centimeters)
84.252 in (inches)
7.021 ft (feet)
Approximate width of the display. If the manufacturer does not provide such information, the width is calculated from the diagonal and the aspect ratio.
|1872 mm (millimeters)|
187.2 cm (centimeters)
73.7008 in (inches)
6.1417 ft (feet)
Approximate height of the display. If the manufacturer does not provide such information, the height is calculated from the diagonal and the aspect ratio.
|1053 mm (millimeters)|
105.3 cm (centimeters)
41.4567 in (inches)
3.4547 ft (feet)
There are various panel technologies. Each has its own specific features - viewing angles, color reproduction, response time, brightness/contrast, production cost, etc. The image quality depends directly on the type of the display panel used.
|Panel bit depth|
The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.
|10 bits (8 bits + FRC)|
Frame Rate Control (FRC) is a method, which allows the pixels to show more color tones. With quick cyclic switching between different color tones, an illusion for a new intermediate color tone is created. For example, by using FRC, a 6-bit display panel is able to show 16.7 millioin colors, which are typical for 8-bit display panels, and not the standard 262200 colors, instead. There are different FRC algorithms.
The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.
The ratio between the horizontal and the vertical side of the display. Some of the standard and widely used aspect ratios are 4:3, 5:4, 16:9 and 16:10.
Information about the number of pixels on the horizontal and vertical side of the screen. A higher resolution allows the display of a more detailed and of higher quality image.
|3840 x 2160 pixels|
Ultra HD (UHD) / 4K / 2160p
The pixel pitch shows the distance from the centers of two neighboring pixels. In displays, which have a native resolution (the TFT ones, for example), the pixel pitch depends on the resolution and the size of the screen.
|0.488 mm (millimeters)|
0.0488 cm (centimeters)
0.0192 in (inches)
0.0016 ft (feet)
Information of the number of pixels in a unit of length. With the decrease of the display size and the increase of its resolution, the pixel density increases.
|52 ppi (pixels per inch)|
20 ppcm (pixels per centimeter)
The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.
|Direct LED (Full-Array Local Dimming)|
Often even a higher peak luminance can be achieved under certain conditions. For example, when a smaller area/APL of the display is used for showing a bright object, when a bright object is displayed for a short time, etc.
|600 cd/m² (candela per square meter)|
HDR expands the contrast ratio (peak luminance and minimal black levels) and color palette to achieve more details across the whole image - from the darkest parts to the brightest ones, which results in more realistic and life-like image.
Dolby Vision IQ
HLG (Hybrid Log Gamma)
|Horizontal viewing angle|
Information about the maximum horizontal viewing angle, within which the image on the screen is of acceptable quality.
|178 ° (degrees)|
|Vertical viewing angle|
Information about the maximum vertical viewing angle, within which the image on the screen is of acceptable quality.
|178 ° (degrees)|
Information on whether 3D is supported or not.
|Vertical frequency (digital)|
The vertical frequency/refresh rate shows how many times in a second the image on the screen is refreshed.
|48 Hz - 120 Hz (hertz)|
Frame interpolation technologies differ according to the manufacturer and each has its own specific name.
|Picture Criteria Index|
The frame interpolation value as provided by the manufacturer. This value must not be confused with the refresh rate of the screen.
|Interpolation measurement unit|
Some manufacturers name commercially the measurement unit of their own interpolation technologies as to denote the degree of interpolation. Very often the measurement unit is an abbreviation of the frame interpolation technology in use.
Permissible voltage tolerance in a 110-volt electric system.
|100 V - 120 V (volts)|
Permissible voltage tolerance in a 220-volt electric system.
|220 V - 240 V (volts)|
|Alternating current frequency|
Requirement regarding the alternating current frequency in the electric system.
|50 Hz - 60 Hz (hertz)|
|Power consumption (sleep)|
Power consumption in sleep/stand by/suspend mode.
|0.5 W (watts)|
Information about the colors, in which the specific model is offered to the market.
Information about whether there is a possibility for wall mounting according to the VESA Mounting Interface Standard (MIS).
There are many various interfaces under the VESA standard, which differ in the size of the brackets, the distances between the screw holes and their number.
Information about whether the stand can be dismounted. Usually, this is required for wall mounting.
Information about whether the stand allows height adjustment.
Some displays have the ability to operate in landscape and portrait mode alike.
Information whether the display can be swiveled around the stand axis.
Most displays have the ability to be tilted forward and backward as to provide a more comfortable viewing position for the user.
Information about the TV tuners, which the current model is equipped with.
|Processor brand name|
Brand name of the processor trademarked by the manufacturer.
|Hi-View Engine (4K)|
The system-on-chip (SoC) integrates different hardware components such as CPU, GPU, memory and others.
The software instructions are performed by the CPU cores. The higher number of cores allows for the parallel (simultaneous) processing of more instructions and achieving higher performance. There are various processors equipped with 1, 2, 4, 6, 8, and more cores.
|Operating system (OS)|
The operating systems of the smart TV sets feature user interface technologies for navigation and other ways of interaction with the smart TV - installing applications, internet browsing, video calls, sharing content with other users, playing videos and music, etc.
The speaker is a device, which converts electrical audio signals into acoustic vibrations resulting in corresponding sounds.
|2 x 10 W (watts)|
Information whether the current model has a built-in camera or not.
Information about the network technologies and standards supported by the model, which allow for it to connect to and communicate with other devices.
802.11a (IEEE 802.11a-1999)
802.11b (IEEE 802.11b-1999)
802.11g (IEEE 802.11g-2003)
802.11n (IEEE 802.11n-2009)
802.11ac (IEEE 802.11ac)
Information about the available connectivity ports, slots and interfaces such as USB, infrared port, SD card slot, audio/video and network interfaces, etc.
|1 x USB 2.0|
1 x USB 3.0
1 x Ethernet RJ45
3 x HDMI 2.0 (CEC)
1 x Satellite In (F-type female)
1 x AV Composite In (Video + L/R)
1 x Optical Audio Out
1 x 3.5 mm Audio Out
1 x Antenna (RF) (female)
1 x CI+ 1.4
|Auto Low Latency Mode (ALLM)|
Enhanced Audio Return Channel (eARC)
High-bandwidth Digital Content Protection (HDCP)
High Frame Rate (HFR)
Variable Refresh Rate (VRR)
Information about additional software features, technologies, functions and services of the model.
|AI 4K upscaling|
AMD FreeSync technology
Game Mode Pro
Low Blue Light
MEMC (Motion Estimation Motion Compensation)
Quantum Dot Color
Ultra Smooth Motion
Wide Color Gamut
|Image file formats|
Information about some of the main image file formats supported by the current model.
|Audio file formats/codecs|
Information about some of the main audio file formats/codecs supported by the current model.
|3GPP (3rd Generation Partnership Project, .3gp)|
AAC (Advanced Audio Coding)
AAC+ / aacPlus / HE-AAC v1
FLAC (Free Lossless Audio Codec, .flac)
M4A (MPEG-4 Audio, .m4a)
MP3 (MPEG-2 Audio Layer II, .mp3)
WMA (Windows Media Audio, .wma)
WAV (Waveform Audio File Format, .wav, .wave)
|Video file formats/codecs|
Information about some of the main video file formats/codecs supported by the current model.
|3GPP (3rd Generation Partnership Project, .3gp)|
AVI (Audio Video Interleaved, .avi)
DivX (.avi, .divx, .mkv)
H.264 / MPEG-4 Part 10 / AVC video
H.265 / MPEG-H Part 2 / HEVC
MKV (Matroska Multimedia Container, .mkv .mk3d .mka .mks)
MP4 (MPEG-4 Part 14, .mp4, .m4a, .m4p, .m4b, .m4r, .m4v)
|Certificates, standards and licenses|
List of the standards, certificates and licenses supported/received by the current model.
|TÜV Rheinland Data Privacy|
The operating temperature shows the safe temperature range (from minimum to maximum), within which the display will function flawlessly. Outside this range it might operate improperly and/or fail entirely.
|5 °C - 35 °C (degrees Celsius)|
41 °F - 95 °F (degrees Fahrenheit)
The operating humidity shows the acceptable level of humidity, in which the display will function flawlessly. It sets a lower and an upper humidity level for safe operation and is measured in percentage.
|20 % - 80 % (percent)|
The storage temperature shows the range from a minimum to a maximum temperature, within which storing of the display is considered to be safe.
|-15 °C - 45 °C (degrees Celsius)|
5 °F - 113 °F (degrees Fahrenheit)
The storage humidity shows the lower and upper humidity limit, which ensures safe storage of the display. Storing it outside these limits might damage the display.
|10 % - 70 % (percent)|
Information about some of the main accessories included in the standard packaging of the current model.
|Voice remote control|
