Comparison between:
- 23.8" Lenovo Legion 24-1r
- 23.8" Lenovo Legion R24s

Brand, series, model

Information about the brand, series, model and model aliases.

Lenovo Legion 24-1rLenovo Legion R24s
Lenovo Legion 24-1rLenovo Legion R24s
Model alias68F8GAC468CBGAC2
Model year20262025

Display

Information about the main characteristics of the display - panel, backlight, resolution, refresh rate, etc.

Size class23.8 in23.8 in
Diagonal604.7 mm
60.47 cm
23.8071 in
1.9839 ft		604.7 mm
60.47 cm
23.8071 in
1.9839 ft
Width527.04 mm
52.704 cm
20.7496 in
1.7291 ft		527.04 mm
52.704 cm
20.7496 in
1.7291 ft
Height296.46 mm
29.646 cm
11.6717 in
0.9726 ft		296.46 mm
29.646 cm
11.6717 in
0.9726 ft
Panel typeIPSIPS
Panel bit depth8 bits (6 bits + FRC)8 bits (6 bits + FRC)
FRCYesYes
Colors16777216 colors
24 bits		16777216 colors
24 bits
Aspect ratio1.778:1
16:9		1.778:1
16:9
Resolution1920 x 1080 pixels
Full HD / 1080p		1920 x 1080 pixels
Full HD / 1080p
Pixel pitch0.275 mm
0.0275 cm
0.0108 in
0.0009 ft		0.275 mm
0.0275 cm
0.0108 in
0.0009 ft
Pixel density92 ppi
36 ppcm		92 ppi
36 ppcm
Display area88.88 %90.06 %
BacklightW-LEDW-LED
sRGB99 %99 %
Brightness400 cd/m²250 cd/m²
Static contrast1000 : 11500 : 1
Dynamic contrast3000000 : 13000000 : 1
HDRHDR10HDR10
Horizontal viewing angle178 °178 °
Vertical viewing angle178 °178 °
Minimum response time1 ms
0.0010 s		4 ms
0.0040 s
Average response time3 ms
0.0030 s		6 ms
0.0060 s
Maximum response time4 ms
0.0040 s		10 ms
0.0100 s
CoatingAnti-glare/MatteAnti-glare/Matte
Response time - 0.5 ms (MPRT - Motion Picture Response time)Response time - 1 ms (MPRT - Motion Picture Response Time)

3D

3D displays use various technologies to achieve a 3D effect. Each of these technologies has its own advantages and drawbacks.

3DNoNo

Frequencies

Information about the horizontal and vertical refresh rates/frequencies.

Vertical frequency (digital)48 Hz - 280 Hz48 Hz - 144 Hz

Power supply and consumption

Information about the power supply and consumption, energy efficiency class, etc.

110V100 V - 120 V100 V - 120 V
220V220 V - 240 V220 V - 240 V
Alternating current frequency50 Hz - 60 Hz50 Hz - 60 Hz
Power consumption (off)0.3 W0.3 W
Power consumption (sleep)0.5 W0.5 W
Power consumption (average)20 W12 W
Power consumption (maximum)34 W28.5 W

Dimensions, weight and color

Information about the dimensions and the weight of the specific model with and without stand as well as the colors, in which it is offered to the market.

Width540.4 mm
54.04 cm
21.2756 in
1.773 ft		539.1 mm
53.91 cm
21.2244 in
1.7687 ft
Height325.3 mm
32.53 cm
12.8071 in
1.0673 ft		321.8 mm
32.18 cm
12.6693 in
1.0558 ft
Depth40.8 mm
4.08 cm
1.6063 in
0.1339 ft		42 mm
4.2 cm
1.6535 in
0.1378 ft
Weight3.9 kg
8.6 lbs		3.1 kg
6.83 lbs
Width with stand540.4 mm
54.04 cm
21.2756 in
1.773 ft		539.1 mm
53.91 cm
21.2244 in
1.7687 ft
Height with stand408.3 mm
40.83 cm
16.0748 in
1.3396 ft		432.3 mm
43.23 cm
17.0197 in
1.4183 ft
Depth with stand214 mm
21.4 cm
8.4252 in
0.7021 ft		184.7 mm
18.47 cm
7.2717 in
0.606 ft
Weight with stand5 kg
11.02 lbs		3.5 kg
7.72 lbs
Box width618 mm
61.8 cm
24.3307 in
2.0276 ft		617 mm
61.7 cm
24.2913 in
2.0243 ft
Box height395 mm
39.5 cm
15.5512 in
1.2959 ft		385 mm
38.5 cm
15.1575 in
1.2631 ft
Box depth149 mm
14.9 cm
5.8661 in
0.4888 ft		126 mm
12.6 cm
4.9606 in
0.4134 ft
Box weight6.9 kg
15.21 lbs		5.7 kg
12.57 lbs
Stand depth214 mm
21.4 cm
8.4252 in
0.7021 ft		184.7 mm
18.47 cm
7.2717 in
0.606 ft
ColorsRaven BlackBlack

Ergonomics

Information about the ergonomic functions - height adjustment, swivel angles, tilt angles, etc.

VESA mountYesYes
VESA interface100 x 100 mm100 x 100 mm
Removable standYesYes
Height adjustmentYesNo
Height adjustment range135 mm
13.5 cm
5.315 in
0.4429 ft		-
Landscape/portrait pivotYesNo
Left pivot90 °-
Right pivot90 °-
Left/right swivelYesNo
Left swivel30 °-
Right swivel30 °-
Forward/backward tiltYesYes
Forward tilt5 °5 °
Backward tilt22 °22 °

Audio

Information about the audio system - number and power of the built-in speakers, supported audio technologies.

Speakers-2 x 3 W

Camera

Many contemporary desktop monitors and smart TV sets have built-in cameras.

CameraNoNo
Modular Camera Support - Lenovo LC 50-

Connectivity

Available connectivity ports, slots and interfaces.

Connectivity2 x HDMI 2.1 (TMDS)
1 x DisplayPort 1.4 (HBR3)		1 x HDMI 2.1
1 x DisplayPort 1.2
High-bandwidth Digital Content Protection (HDCP)High-bandwidth Digital Content Protection (HDCP)

Features

Some additional functional features of the model.

Features3-side NearEdgeless design
AMD FreeSync Premium
Brightness Calibration
Gaming Console Support
Lenovo Artery
Natural Low Blue Light
VESA AdaptiveSync Display 280Hz		3-sided NearEdgeless design
Flicker-free technology
Natural Low Blue Light
VESA MediaSync Display

Certificates, standards and licenses

Licenses from regulatory agencies, standards, certificates.

Certificates, standards and licensesEyesafe Certified 2.0
RoHS
TÜV Rheinland Low Blue Light (Hardware Solution)		Eyesafe Display Certification 2.0
RoHS
TÜV Rheinland Flicker-free Certified
TÜV Rheinland Low Blue Light Certified (Hardware Solution)

Operating and storage conditions

There are certain requirements for the environmental conditions, in which the display should be used and stored in order to function properly.

Operating temperature0 °C - 40 °C
32 °F - 104 °F		0 °C - 45 °C
32 °F - 113 °F
Operating humidity8 % - 80 %10 % - 80 %
Operating altitude5000 m
16404.2 ft		5000 m
16404.2 ft
Storage temperature-20 °C - 60 °C
-4 °F - 140 °F		-20 °C - 60 °C
-4 °F - 140 °F
Storage humidity5 % - 95 %5 % - 95 %
Storage altitude12192 m
40000 ft		12192 m
40000 ft

Accessories

Often the packaging of desktop monitors and smart TV sets includes accessories for them.

AccessoriesDisplayPort cableDisplayPort cable

Additional features

Information about other features.

Additional featuresAnti-theft stand lock slot - KensingtonAnti-theft stand lock slot - Kensington
 Lenovo Legion 24-1rLenovo Legion R24s
